MULTI-POINT TEMPERATURE SENSOR

Protection Tubes : High Purity Quartz, Alumina and Special SiC tube

Thermocouple : Type R, S and B

Measuring points : 2〜5 max.

Measuring range : Type R and S 1200℃ (Quartz Tube), Type B 1600℃ (Alumina Tube)

Length of Assembly : 1〜2 meters

Overall Dia. of Assembly : 12〜25 mm.

Accuracy : Standard Grade ±0.25% of Reading.

                 Premium Grade ±0.1% of Reading (Type R only)*SiC tube is optional, but sometimes needs to protect thermocouple wires from                                  contamination by inner protective coating or clean Alumina inner tube, etc.
